| MODEL | ZS600I-TV | ZS700I-TV | ZS7060-TV | ZS600II-TV | ZS700II-TV | |
| ILLUMINATION (lx) | 80000-160000 | |||||
| COLOR TEMPERATURE (K) | 3000-6000 | |||||
| COLOR RENDERING INDEX (Ra) | ≥93 | |||||
| SPOT DIAMETER (mm) | 100-250 | |||||
| ILLUMINATION DEPTH (mm) | ≥600mm | |||||
| PHYSICIAN HEAD WARMING | ≤2℃ | |||||
| HEIGHT ADJUSTMENT (mm) | 约800 | |||||
| DIAMETER OF LAMP CAP (mm) | MAIN LIGHT | 600 | 700 | 700 | 600 | 700 |
| SIDE LAMP | / | / | 600 | 600 | 700 | |
| BRIGHTNESS ADJUSTMENT | Nine tone dimming | |||||
| POWER SUPPLY (W/Hz) | A.C.220V 50Hz | |||||
| INPUT POWER (W/A) | 400 | |||||
| BULB (W/V) | 214V/150w Halogen bulb | |||||
| SECURITY TYPE | Class I | |||||
| FITTING PARAMETER | ||||||
| PICK UP DEVICE | 1/4″super HADIT CCD | |||||
| HORIZONTAL RESOLUTION | 540 Line | |||||
| SIGNAL TO NOISE RATIO | 50db | |||||
| ZOOM | 30× OPTICS (f=3.55~113mm)8× DIGITAL | |||||
| PLAYBACK IMAGE QUALITY | main road D1(704×576)、3路CIF(352×288) | |||||
| VIDEO CAMERA POWER SUPPLY | 12V DC±10%4W | |||||
| Our factory preserves column specifications and pictures, to the website in the text and change the rights of additions and deletions | ||||||
